23 Whelan Street, Armstrong Creek VIC 3217

A 2-Participant High Physical Support Home

Ceiling Hoist Ready | Step-Free Access Throughout | Reverse Cycle Air Conditioning | OOA Included

23 Whelan Street, Armstrong Creek is a purpose-built 2-participant SDA home assessed and certified under the High Physical Support design category. This is a brand-new single-storey house, assessed at final-as-built stage by an NDIS accredited SDA assessor and certified as fully compliant with the NDIS SDA Design Standard Edition 1.1.

This home has been built for participants who need a higher level of physical support and who deserve a home that genuinely meets those needs without compromise. From ceiling hoist infrastructure in every participant bedroom to step-free access throughout, wide doorways, emergency power provisions, and accessible wet areas, every element of this home has been designed and delivered to a high standard from the ground up.

A dedicated Overnight On-Call (OOA) room is included so that overnight support can be provided when needed, giving participants the reassurance of support nearby while still living with real independence and privacy.

The Heart of the Home

Open, Comfortable and Easy to Move Around In

The living area is the centre of the home, designed to feel open, welcoming, and easy to navigate for wheelchair users and those with significant mobility support needs. The layout provides the required clear turning space, and the connection between living, kitchen, and outdoor areas makes everyday life feel natural and unrestrained.

Dimmable lighting is provided in the living areas and bedrooms, giving participants and support workers full control over comfort and atmosphere. Light switches and power points are positioned at consistent, accessible heights throughout the home to support independence in everyday routines.

Reverse cycle air conditioning is provided to the living areas and bedrooms, with control panels installed at accessible heights between 900mm and 1100mm from floor level so participants can adjust their environment without assistance.

Participant Bedrooms

Private, Accessible and Built for Real Independence

Both participant bedrooms have been designed to support the specific needs of High Physical Support participants. Each bedroom is large enough to accommodate a Queen-sized bed with wide circulation clearances on three sides, including a minimum 1540mm clearance on one side to allow for hoist transfers and support worker access.

Each bedroom includes a robe of 1400mm width with adequate clearance in front, providing real storage without sacrificing circulation space.

Critically, both participant bedrooms have been structurally certified by a qualified engineer as capable of supporting a constant-charge ceiling hoist with a minimum 250kg load capacity. The hoist infrastructure is in-built and ready for installation, capable of travelling across and down the bed. This is a mandatory requirement of the High Physical Support design category and has been certified as complete.

Power and cabling has been provided to the head of all entry doors of participant bedrooms and external entry doorways for future door automation. Emergency power solutions are installed to ensure a minimum two-hour outage capacity across no fewer than two double GPOs in each participant bedroom and at any automated entry and egress doors.

Multiple double GPOs are provided at the bed head wall and on the opposing wall in each bedroom, supporting the use of assistive technology, medical equipment, and personal devices.



Bathrooms and Wet Areas

Designed to the Full High Physical Support Standard

The accessible bathroom has been designed and certified to meet all AS1428.1 requirements for the High Physical Support design category.

The shower is positioned in the corner of the room with the required circulation space. A shower curtain rail is provided around the full shower space. A height-adjustable shower head and hose, a vertical support grab rail, and a lever-style shower tap located within the required accessible zone are all provided as part of the design.

The toilet has been positioned to comply fully with accessible toilet requirements, including the correct clearance from the side wall, front edge clearance, flush controls that are proud of the surface, and meets the required minimum circulation space. Wall reinforcement of minimum 12mm thick sheeting has been installed from floor level to a height of 2100mm throughout the sanitary compartments, ensuring that grab rails and future modifications can be safely installed anywhere they are needed.

The hand wash basin is AS1428.1 compliant, with a minimum depth of 430mm, knee and toe clearance underneath, and lever or sensor-style tapware located within reach.

Slip resistance across all wet area flooring meets the minimum required standard for the High Physical Support design category.

Kitchen

Accessible, Practical and Support-Friendly

The kitchen has been designed to meet the full High Physical Support kitchen requirements. It includes a fixed cooktop with rangehood, an in-built wall oven, a sink with lever tapware, a drawer-style dishwasher, and a wheelchair-accessible pantry.

A height-adjustable benchtop is provided, capable of adjusting from 720mm to 1020mm clear space underneath, allowing participants to work comfortably from a seated or standing position. An accessible fixed benchtop of minimum 600mm depth is also positioned next to the cooktop and wall oven, with knee and toe clearance underneath in accordance with AS1428.1.

At least 1550mm of clearance is provided in front of all fixed benches and appliances, ensuring wheelchair users can move freely and safely through the kitchen space. Task lighting is provided above all work surfaces, meeting the minimum 300 lux standard at the bench top.

D-pull cupboard handles are provided to below-bench and overhead cabinetry, making everyday use manageable without requiring fine grip or wrist rotation.



Laundry

Practical and Fully Accessible

The laundry is equipped with a sink or tub with lever-style tapware, accessible clearance in front of all benches and appliances, and slip-resistant flooring to the required standard. It has been designed to allow participants and support workers to move comfortably within the space without obstruction.



Outdoor Area

Safe, Step-Free and Easy to Enjoy

The home includes external outdoor space accessible via step-free threshold doorways. Slip-resistant flooring is provided in all external areas, helping make outdoor spaces safer for participants with mobility equipment or support needs.

The accessway from the front boundary of the site to the entry doorway is safe, continuous, and completely step-free, meeting the full High Physical Support standard. A covered roof is provided over the required landing area at the main external entry doorway. The accessible car parking space is a minimum 3800mm wide by 5400mm long, with a slip-resistant, level surface and a roof over the space.



Accessibility and Assistive Technology

Built to the High Physical Support Standard from the Ground Up

This home has been certified at the final-as-built stage by an NDIS-accredited SDA assessor and is fully compliant with the NDIS SDA Design Standard Edition 1.1 for High Physical Support.

Key features include:

• Step-free access from the site boundary through to all areas of the home
• Minimum 950mm clear opening width to all doorways used by participants
• Minimum 1200mm clear corridor widths throughout
• Ceiling hoist-ready structure in all participant bedrooms, certified by a qualified structural engineer for a minimum 250kg constant-charge hoist
• Emergency power solutions for a minimum 2-hour outage across GPOs in bedrooms and at automated entry and egress doors
• Reverse cycle air conditioning in living areas and bedrooms, with accessible controls
• High-speed internet connection with stable Wi-Fi coverage throughout the home
• Video or intercom communication system to support communication between participants and their support workers
• Dimmable lighting in living areas and bedrooms
• Consistent light switch and GPO heights throughout, with rocker-action or push-pad switches of minimum 35mm width
• Slip-resistant flooring across all internal and external areas to the required standard
• Carpet, where provided, meeting the maximum pile height and backing thickness requirements
• Window sills in living areas and participant bedrooms positioned no higher than 1000mm from floor level
• Lockable windows with controls within easy reach
• Cabling provided at windows for future blind automation
• Smoke alarms in bedrooms and living spaces
• Emergency evacuation plan provided
• AS1428.1 compliant letterbox at the correct accessible height and on a hard-standing accessible area
• A storage cupboard with a minimum 600mm width and adjustable shelf heights
• A living area clear space of minimum 2250mm diameter, clear of furniture



Location

23 Whelan Street is located in Armstrong Creek, a growing residential suburb in the greater Geelong region of Victoria. The area provides participants and support providers with straightforward access to everyday services, medical facilities, and transport options.



Shopping

Robinsons Rise Reserve
Robinsons Rise Estate, Cobblebank VIC 3338
Approx. 3 minutes by car
Most suitable transport: car or support vehicle

Torquay Central Shopping Centre

40 Gilbert Street, Torquay VIC 3228

Approximately 15 minutes by car

Most suitable transport: car



Parks and Outdoor Spaces

Armstrong Creek District Park

Fitzpatrick Boulevard, Armstrong Creek VIC 3217

Approximately 5 minutes by car

Most suitable transport: car or support vehicle

Lake Pertobe Adventure Playground and Parkland

Pertobe Road, Warrnambool VIC 3280

Approximately 2 hours 20 minutes by car

Most suitable transport: car



Medical

Armstrong Creek Medical Centre (local GP and health services)

Surf Coast Highway, Armstrong Creek VIC 3217

Approximately 5 minutes by car

Most suitable transport: car or support vehicle

University Hospital Geelong

272-322 Ryrie Street, Geelong VIC 3220

Approximately 20 minutes by car

Most suitable transport: car or support vehicle



Transport

Bus services operate in the Armstrong Creek area with stops accessible from Surf Coast Highway and surrounding streets.

Surf Coast Highway, Armstrong Creek VIC 3217

Approximately 5 minutes by car or short distance by accessible vehicle

Most suitable transport: car or support vehicle

Geelong Train Station (regional and metro connections)

Railway Terrace, Geelong VIC 3220

Approximately 20 minutes by car

Most suitable transport: car or support vehicle
